TRIAX 492773 TDmH 8S-I DVB-S/S2 and IPTV with CI to DVB-T/C &/or IPTV MINI Headend

Triax NEW: TDmH 8S-I 492773 MINI Commercial TV Headend System is the perfect platform to support remote area VAST satellite services in Australia.   This unit can receive satellite transmissions, decode via CAM & Smartcard in CI slots (VAST capacity 40 services) and output to DVB-T COFDM and/or Multicast IPTV UDP/RTP.

The perfect solution for VAST Remote Satellite FTA TV, decode with CAM & Smartcards up to 40 TV and Radio services and suitable for any region in Australia. Output to RF DVB-T UHF or upgrade to enable Multicast IPTV featuring a full 8 day EPG, Digital Channel ID and Now & Next Program Information. Include additional services via HDMI with the TDHI 4H-IP

Built on the same cutting-edge and well-tested software platform used for TD(c)H Compact Headend, but with reduced capacity to meet the requirements for an entry-level headend.  Complimentary updated software offers new and existing customers additional functions, benefits, and powerful hardware configurations to match your requirements.

Features 492773 TDmH-8S-I

• 8x DVB-S/S2 Satellite Transponder INPUTS
• 4x Common Interface Slots for CAM and Smartcards
• 8x DVB-T COFDM UHF Adjacent Channel OUTPUT
• License Upgradeable for simultaneous Multicast IPTV OUTPUT (Maximum 48 IP-out SPTS UDP/RTP)
• License Upgradeable for Multicast IPTV INPUT for conversion to DVB-T COFDM OUT (Maximum 48 IP-in SPTS and MPTS UDP/RTP)
• License Upgradeable for SNMP monitoring protocols
• Channel Multiplexing for both RF and IP output

Compact excellence

• Exquisite engineering, finely tuned for perfect performance
• Your natural choice for swift, efficient TV distribution
• Save time and costs, with fast, easy installation and remote management
• Compact design fits elegantly into 19” rack or as a wall mount unit.
• Reliable, innovative headend expertise from TRIAX

Smooth integration

• Optimised channel setup with advanced multiplexing and Service Pool technology
• No need for retuning TV sets in rooms thanks to SID and PID Management
• EPG Management ensures full Electronic Program Information (EPG) for better user experience
• Multiple language service allows for multiple distribution of a service with different audio (language) tracks
• IP-in and IP-out for receiving and streaming services. Possibility for simultaneous IP-in and IP-out through the same interface with optional VLAN tags for separating the in and out streams
• RF output available either as QAM or COFDM modulation.

Energy saving – long-term reliability

• Low power consumption
• Temperature controlled cooling system with integrated fans – increases the service life of the equipment
• The cooling system supports 19“ rack mounting as well as wall mounting
